*尺寸:94(L) × 43(W) × 15(H) mm
*材質:ABS
*讀取距離:7~15 公分 ( 因卡片規格而異 )
*感應頻率:125KHz / 13.56MHz
*讀取卡片種類
125KHz
EM4100, EM4102, EM4200, TK4100, EM4305, ATA5577, T5567, Temic5557
13.56MHz
Mifare 1 S50, NTAG203, NTAG213, NTAG215, NTAG216,
FM11RF08, IS23SC4439, GT23SC4439, Mifare 1 S70,
GT23SC4469 4K, FM11RF32, Mifare Ultralight ,
Mifare plus S 2K/4K, Mifare DESFire EV1 8K,
Mifare DESFire EV2, SRT512, SRIX4K, ICODE SLI,
ICODE-2, Tag-it HF-I standard, Tag-it HF-I Pro,
Tag-it HF-I Plus, TI256, LEGIC, RC-S962(FeliCa),
RC-S966(FeliCa Lite-S), NFC Tag, LRI2K
電源:DC 5V / 12V / 24V±10%, DC 7V~32V(選項)
通信介面/格式:維庚26/34/42/44/64 bits / ABA Track2( 磁卡第二軌 ) / RS232 / RS485 / USB
使用環境:-10 ℃ ~ 75 ℃
Mifare is a registered trademark of NXP B.V.
MIFARE DESFire is a registered trademark of NXP B.V.
FeliCa is a trademark of Sony Corporation.
所載規格，本公司有修改權利，如與實品不符，以實品為準
